Knowing how to measure a wall for panels starts with more than multiplying the wall’s width by its height. For acoustic slat panels, you need to confirm the exact product dimensions, measure the wall at several points, record doors, windows, corners and fittings, and plan where the first and last slats will sit.
The most reliable approach is to choose your panel first, work in millimetres, calculate each wall separately and round the required number of full panels up rather than down. This helps you plan cuts and avoid discovering during installation that the wall is slightly wider, taller or less square than expected.
| What to check | Why it matters |
|---|---|
| Wall width and height | Determines the basic coverage required |
| Panel length and width | Determines how many full panels fit across the wall |
| Panel thickness | Affects projection from the wall and detailing around edges |
| Doors and windows | May require cut-outs rather than simply reducing the panel count |
| Power points and cabling | Must be included in the installation layout |
| Corners and edge slats | Can change where panels should start and finish |
| Finish direction | Helps maintain a consistent visual layout |
How to Measure a Wall for Panels: Quick Answer
Measure the wall’s width and height at several points rather than relying on a single reading. Record doors, windows, skirting, corners, switches and other interruptions. Then compare those measurements with the exact dimensions of the acoustic panel you intend to buy. Calculate the number required from the actual layout and round up to whole panels. Always confirm the product dimensions before ordering.
What Acoustic Panel Sizes Does EMU Design Offer?
There is no single standard answer to acoustic panel sizes. Length, width and thickness can vary between products and panel ranges, so the selected product should be confirmed before calculating quantities.
Current examples from EMU Design include:
| Product | Length × Width × Thickness |
|---|---|
| Black 3002 | 2400 × 600 × 19 mm or 2700 × 600 × 19 mm |
| Natural Oak 26WV | 2700 × 600 × 18 mm |
| Light Oak Flexible Acoustic Panel | 2700 × 600 × 12 mm |
These dimensions illustrate why measuring the wall before choosing a product can be misleading. A 2400 mm panel and a 2700 mm panel may have the same width but require very different height cuts or joins depending on the room.
Always recheck the individual product page before ordering because dimensions, variants and stock can change. You can also compare EMU Design’s Acoustic Slat Panels and Flexible Acoustic Panels before finalising your measurements.
Measure the Wall Step by Step
For most vertical acoustic slat installations, panel width is particularly important because it determines how many panels are required across the wall.
The following process keeps the measurement tied to the planned installation rather than simply treating the project as an area calculation.
- Choose the area you want to cover. Decide whether the acoustic panels will cover the entire wall, a section of the wall, a TV backdrop or another feature area.
- Sketch the wall. Draw a simple front view and record the position of doors, windows, corners and other fixed elements. The drawing does not need to be perfectly to scale.
- Measure the width at several heights. Measure near the floor, around the centre and towards the ceiling. Walls are not always perfectly parallel, so record the largest measurement as well as any noticeable variation.
- Measure the height at several positions. Check the left side, centre and right side. This is especially important when using a full-height panel because ceilings and floors can vary slightly.
- Record interruptions. Mark skirting boards, cornices, power points, switches, wall lights, data points, vents, cabling and any other item that affects cutting or installation.
- Plan the edges and corners. Consider whether you want a full slat, partial slat or backing section visible at each end. A balanced feature wall may require adjusting the starting point rather than simply beginning with a full panel at one corner.
- Calculate each wall separately. If the panels continue around a corner, calculate each wall independently before considering whether usable offcuts can be transferred between sections.
- Double-check everything. Repeat critical measurements before ordering, particularly the total width, maximum height and locations of cut-outs.
Do not use the room’s floor area to estimate wall panels. Floor dimensions do not tell you the actual wall coverage or account for the selected panel width and orientation.
Calculate Panel Quantity and Cuts
For a straightforward wall using vertically installed panels, the quickest quantity calculation is based on the wall width:
Panels required across wall = wall width ÷ usable panel width
Always round the result up to the next whole panel.
For example, suppose a wall is 4100 mm wide × 2700 mm high and the selected panel is 2700 × 600 mm. The width calculation is:
4100 ÷ 600 = 6.83
You therefore need at least 7 full panels to span the wall. Six panels would cover only 3600 mm, while seven provide 4200 mm of nominal width, leaving approximately 100 mm to be trimmed or incorporated into the planned edge layout.
Area can be used as a secondary check:
Wall area = wall width × wall height
For the example:
4100 × 2700 = 11,070,000 mm² = 11.07 m²
A 2700 × 600 mm panel has a nominal face area of 1.62 m², so:
11.07 ÷ 1.62 = 6.83 panels
Again, the result rounds up to seven. However, area alone is not enough when doors, windows, slat alignment or narrow edge pieces affect the layout.
Acoustic Panel Measurement Worksheet
| Measurement | Your Project |
|---|---|
| Wall width | _____ mm |
| Maximum wall height | _____ mm |
| Selected panel length | _____ mm |
| Selected panel width | _____ mm |
| Selected panel thickness | _____ mm |
| Doors/windows | _____ |
| Switches/power points | _____ |
| Panels calculated across wall | _____ |
| Planned edge cuts | _____ |
| Final quantity | _____ |
Do not automatically subtract every door or window from the total and assume the saved area equals fewer full panels. If a window sits in the middle of a panel run, panels may still need to continue above, below or beside it so the slat pattern remains aligned.
Offcuts can sometimes be reused, but this depends on their dimensions, the direction of the finish and where joins are acceptable. For the same reason, there is no universal waste percentage that suits every acoustic panel project. A simple rectangular wall may create relatively little waste, while walls with multiple corners, openings or detailed edge cuts can require more material.
If you are still deciding whether slatted panels suit the project, the What Are Acoustic Slat Wall Panels? guide can help explain their construction and typical applications before you finalise the layout.
How Thickness and Slat Size Affect the Choice
When comparing acoustic slat panel dimensions, do not confuse overall panel thickness with the dimensions of the individual slats. Several measurements can influence the appearance and installation: overall panel length, overall panel width, panel thickness, individual slat width, spacing or gap between slats, and the thickness and type of backing.
For example, an 18 mm panel and a 19 mm panel will project differently from the wall, while a 12 mm flexible panel may suit a different installation requirement. The acoustic panel slat size and spacing also affect the visual rhythm of the finished wall. These differences matter around door frames, cabinetry, skirting, corners and adjoining finishes.
How Thick Should Acoustic Panels Be?
There is no universal thickness that is automatically “best”. Thickness should be selected according to the specific panel system, installation details, available depth and intended application.
A thicker decorative acoustic panel should also not automatically be assumed to provide better acoustic performance. Acoustic results depend on the full construction, including slats, backing, mounting arrangement and surrounding surfaces. If measured acoustic performance is important to the project, compare relevant manufacturer or laboratory test data rather than choosing on thickness alone.
Final Checks Before Ordering
Before placing an order, confirm the exact product variant and dimensions one final time. Check that the available panel length works with the maximum wall height and that the chosen width matches the quantity calculation. Also confirm the finish and current stock, particularly when several panels need to be installed together.
Review the wall substrate and installation method as well. Fixings, adhesives and cutting methods can vary between products and surfaces, and ceiling installations may have additional requirements compared with standard wall applications. Identify all major cuts before ordering so power points, corners, openings and adjoining finishes are not treated as surprises during installation.
For projects where the quantity or layout is unclear, send your measurements, photos of the wall and preferred finish to Contact EMU Design. This gives the team more useful information for checking the proposed panel quantity before you order.
FAQs
What Size Are Acoustic Slat Panels?
Acoustic slat panels do not come in one universal size. EMU Design currently carries products in different lengths and thicknesses. Examples include Black 3002 at 2400 or 2700 × 600 × 19 mm and Natural Oak 26WV at 2700 × 600 × 18 mm. Confirm the exact product before calculating your quantity.
How Thick Should Acoustic Panels Be?
The appropriate thickness depends on the panel construction, available installation depth and project requirements. EMU Design products can differ in thickness; for example, the standard slat products and flexible panel range do not necessarily use the same overall depth. Do not assume that a thicker panel automatically provides better acoustic performance without suitable test data.
Do I Subtract Doors and Windows?
Record doors and windows, but do not automatically subtract their full area from the order quantity. The surrounding panels may still need to maintain continuous slat alignment, and sections may be required above, below or beside the opening. Plan the actual panel layout first, then determine which cut-outs produce reusable offcuts.
Measure First, Then Order
A reliable acoustic panel order starts with the wall dimensions and the specific product, not an assumed standard panel size. Measure width and height at several points, record obstacles, compare the results with the chosen acoustic slat wall dimensions and calculate the layout using the panel’s actual width.
Before ordering, check the dimensions and finish again and plan the visible edges and major cuts. If you want a second check, send EMU Design your wall measurements, clear photos and chosen panel finish so the proposed quantity can be reviewed before purchase.
